four module pick and place machine high accuracy multifunctional led making machine
Introducing machine RT-4
The machine is four module magnetic linear motor multifunctional placement machine,total 40 heads and 80 feeders station.
Feature of machine
- Highspeed multifunctional LED pick and place machine
- The X Y Z axis is magnetic linear motor and serve motor,very good performance and high accuracy.
- Its high accuracy,apply to LED,resistors,capacitors,IC,shaped components etc.
- It is high speed pick and place machine,the optimum speed is 120000-140000 CPH.
Technical parameter
| Model | RT-4 |
| Dimension | 2086*2237*1500mm |
| Total weight | 4500kg |
| PCB | size | Max:500*310mm Min:50*50mm |
| Thickness | 0.1-6mm |
| Clamping | Electric clamping |
| Mounting mode | Group picking and separate placing,separate picking and separate placing. |
| O.S. | System | Windows 7 |
| Software | R&D independently |
| Display | Touch screen monitor |
| Input device | Keyboard,mouse |
| Vision system | camera | 8 PCS digital camera |
| Mounting precision | 0.02mm |
| Mounting element height | ≤7.5mm |
| Mounting speed | 120000-140000 CPH |
| Components | LED3014/3020/3528/5050 and capacitor,resistors,IC,shaped components,etc. |
| Feeder station | 80 PCS |
| Nozzles | 20 PCS |
Exclusive patented technology
- Electric feeder feeding system
- Vision alignment flight identification,Mark correction
- Auto-optimization after coordinates generated etc.
Application
| Model | PCB size | Product application examples |
| RT-4 | Max:500*310mm Min:50*50mm | LED bulb,down-light,streetlight,driver,electric board |
Company profile
- ETON enjoys a good reputation in China. It was established in 2011 and has more than ten years of experience. It is a manufacturer specializing in the production of SMT machines.
- ETON Industrial Park was successfully completed in Jiangxi, introducing the most advanced production technology and equipped with 45,000 square meters of production workshops.
- With offices overseas, offices in India, and local engineers in Egypt and Turkey, we can better serve you
Exhibition
We also have many exhibitions, such as the domestic Shanghai Munich exhibition, and foreign India Delhi exhibition, India Mumbai exhibition, Pakistan exhibition, Turkey exhibition, Thailand exhibition and so on.
Company after-sales service
- The warranty period is one year. During the warranty period, parts can be replaced free of charge
- Free installation and training
- Free software updates are provided
About our machine packaging
We use wooden box vacuum packaging, which can protect the machine very well.
FAQ:
Do our machines only for LED lights?
No,our machines apply to not only LED light but also other products.
What components do our machines apply to?
Our machines can patch LED 3014/30202/2835/5050/5630/5730 etc.. capacitors, resistors,IC.shaped components and so on.
Why do we adopt the smart electronic feeders?
Our machines adopt the smart electronic feeders which are more stable.universal and intelligent. The feeding speed of electronic feeder is faster than the traditional pneumatic feeder.It can avoid the cost and drop of materials effectively.How is the breakdown rate of machine?
Our machine is very stable,the breakdown rate is less than 0.001;.
Is your software interface in English?
English interface and Chinese interface are both available.
Why your price is so high?
Because the quality, accuracy and performance of our machines are relatively good,different but better.
